TM-426 six-channel tablet and capsule counter

Overview

What it does

The TM-426 feeds and counts tablets and hard or soft capsules into bottles at up to 2,000 pieces a minute. Six vibratory tracks run at independently variable speed, and because counting is optical rather than mechanical there are no change parts to swap when you move from a #0 capsule to a tablet. A PLC and touch screen handle both the count and the indexing of the bottle underneath, and an air cylinder pushes the next batch of containers into the filling position. Dust is pulled out by a vacuum system, so the hoppers stay clean through a shift.

Key features

• Six tracks with variable speed control, so each track can be tuned to the product.
• Vibratory linear feeding handles any shape: tablets, hard shell capsules and soft gels.
• No change parts between products. Counting is set on the screen, not with tooling.
• Pre-counting raises throughput by staging the next dose while the bottle indexes.
• Tool-free release for changing over to a different product.
• Air cylinder indexing drives the next batch of containers into the filling position.
• Vacuum dust extraction keeps the tracks and hoppers clean through a shift.
• Delta PLC with a touch screen, so settings are recalled rather than reset by hand.
• Three-colour indicator light and emergency stop in reach of the operator.
• Frame and components in SUS#304 stainless steel and ion anodised aluminium.
• 850 mm conveyor height, matched to every other station in the line.
